Reinforcement Systems
PYRAPLEX® - Double leg U-bar, stirrup width 9 cm, box width 11.2 cm
PYRAPLEX® is a prefabricated reinforcement system for easy and safe connection of reinforced concrete components of different construction sections. PYRAPLEX® is a further development of the PLEXUS® box with recesses for high shear forces. With the new and unique special pyramid design of the box, PYRAPLEX® is the first product to ensure biaxial transfer of shear forces along the entire length of the construction joint. The surface finish of the storage box is classified as "geared" according to the DBV leaflet "Rebending of reinforcing steel and requirements for storage boxes". No risk of injury due to plastic cover.
| Item no. | For wall thickness from mm | Ø Iron mm | Stirrup distance "s" cm | Pull out length "lü" cm | Box height mm | Length m | m Bundle | m Pallet |
|---|---|---|---|---|---|---|---|---|
| BKV081009E | 160 - 180 | 8 | 10 | 32 | 30 | 1,25 | 7,50 | 120,00 |
| BKV081509E | 160 - 180 | 8 | 15 | 32 | 30 | 1,25 | 7,50 | 120,00 |
| BKV082009E | 160 - 180 | 8 | 20 | 32 | 30 | 1,25 | 7,50 | 120,00 |
| BKV101009E | 160 - 180 | 10 | 10 | 39 | 50 | 1,25 | 7,50 | 120,00 |
| BKV101509E | 160 - 180 | 10 | 15 | 39 | 36 | 1,25 | 7,50 | 120,00 |
| BKV102009E | 160 - 180 | 10 | 20 | 39 | 36 | 1,25 | 7,50 | 120,00 |
| BKV121509E | 160 - 180 | 12 | 15 | 46 | 50 | 1,25 | 7,50 | 120,00 |
| BKV122009E | 160 - 180 | 12 | 20 | 46 | 40 | 1,25 | 7,50 | 120,00 |
