Reinforcement Systems
PLEXUS® - Double leg U-bar, stirrup width 9 cm, box width 11.5 cm
PLEXUS® is a prefabricated reinforcement system for easy and safe connection of reinforced concrete components of different construction sections. Walls, ceilings, brackets or stairs are subsequently reliably connected to each other. The surface finish of the storage box is classified as "smooth" according to the DBV leaflet "Rebending of reinforcing steel and requirements for storage boxes". No risk of injury due to plastic cover.
| Item no. | For wall thickness from mm | Ø Iron mm | Stirrup distance "s" cm | Pull out length "lü" cm | Box height mm | Length m | m Bundle | m Pallet |
|---|---|---|---|---|---|---|---|---|
| B121009E | 160 - 180 | 12 | 10 | 46 | 50 | 1,25 | 7,50 | 120,00 |
| BK081009E | 160 - 180 | 8 | 10 | 32 | 30 | 1,25 | 7,50 | 120,00 |
| BK081509E | 160 - 180 | 8 | 15 | 32 | 30 | 1,25 | 7,50 | 120,00 |
| BK082009E | 160 - 180 | 8 | 20 | 32 | 30 | 1,25 | 7,50 | 120,00 |
| BK082509E | 160 - 180 | 8 | 25 | 32 | 30 | 1,25 | 7,50 | 120,00 |
| BK101009E | 160 - 180 | 10 | 10 | 39 | 36 | 1,25 | 7,50 | 120,00 |
| BK101509E | 160 - 180 | 10 | 15 | 39 | 36 | 1,25 | 7,50 | 120,00 |
| BK102009E | 160 - 180 | 10 | 20 | 39 | 36 | 1,25 | 7,50 | 120,00 |
| BK102509E | 160 - 180 | 10 | 25 | 39 | 36 | 1,25 | 7,50 | 120,00 |
| BK121509E | 160 - 180 | 12 | 15 | 46 | 36 | 1,25 | 7,50 | 120,00 |
| BK122009E | 160 - 180 | 12 | 20 | 46 | 36 | 1,25 | 7,50 | 120,00 |
| BK122509E | 160 - 180 | 12 | 25 | 46 | 36 | 1,25 | 7,50 | 120,00 |
